Specialty Seafood Tank

Sub Title

Product No.

Designed to fit the special-need requirements of Marineland retail customers, our Specialty Display and Holding Systems exhibit the ultimate in space, service and product-display flexibility. And when the express need is for a high-capacity holding system, Marineland rises to meet that demand, as well. Many of our specialty systems are also available with the patented Marineland BIO-Wheel®.Go above and beyond with your lobster, trout or catfish tank when you choose a specialty seafood tank display from Marineland!

Our BIO-Wheel filtration module provides a simple, yet superior solution to three-stage system filtration. Easy to install, easy to maintain, it significantly reduces labor cost while dramatically increasing filtration efficiency.

As water enters the module, waste is mechanically trapped by a poly-fiber prefilter pad. The carbon filter pack contains Black Diamond® premium activated carbon for chemical filtration, efficiently adsorbing dissolved organic compounds.

Passing through the filter media trays, water flows onto the BIO-Wheel wet/dry biological filter mounted below. Because system flow causes it to rotate, the BIO-Wheel is constantly exposed to both water and air, thus developing a thriving culture of aerobic nitrifying bacteria.

Tank Abbreviations
FV - Forward View
SS - Shellfish
SI - Slide-In

SPECIAL FEATURES
  • Refrigeration Unit - Maintains tank temperatures of 45°-70°F and can be preset to the exact temperature required by the system.
  • UV Disinfection Unit - Helps stop the spread of bacteria and disease throughout the system.
  • Protein Skimmer - Employs heavy aeration to remove organic matter from the tank in the form of foam.

All systems also available in 220/240V, 50 Hz.

Many of our systems are available with Marineland BIO-Wheel wet/dry biological filtration. BIO-Wheel improves system water quality, lowers maintenance and increases holding capacity.
WHERE TO PURCHASE

Cantilevered design intended to complement a self-service case or other front-access display. DIMENSIONS: 49" L x 35"W x 56-70" H (Height per customer request); SHIP WEIGHT: 650 Lbs

DIMENSIONS: 27-1/4" L x 27-1/4"W x 47" H; SHIP WEIGHT: 300 Lbs.; CAPACITY: 9 Gallons; RECOMMENDED LOAD: Shellfish 2-1/2 Bushels; POWER REQUIRED: 15 Amps, 115V, 60Hz; Lighting available.

DIMENSIONS: 50" L x 27-1/4"W x 53" H; SHIP WEIGHT: 675 Lbs.; CAPACITY: Lobster Tank: 50 Gallons; Shellfish Tank: 9 Gallons (Reservoir); POWER REQUIRED: 20 Amps, 115V, 60Hz; Lighting available.

DIMENSIONS: 10' L x 4'W x 3' H; SHIP WEIGHT: 700 Lbs.; PLUS SIDE PALLET: 790 Lbs.; CAPACITY: 360 Gallons; Refrigeration/Filtration (1); Product Holding (2);

RECOMMENDED LOAD: Lobster 500 Lbs.; POWER REQUIRED: Refrigeration/Filtration: 15 Amps, 220V, 60Hz; Pump: 5 Amps, 115V, 60Hz

DIMENSIONS: 10' L x 4'W x 5'H; SHIP WEIGHT: 900 Lbs.; PLUS SIDE PALLET: 890 Lbs.; CAPACITY: 560 Gallons; TRAYS: Refrigeration/Filtration (1); Product Holding (2); REC LOAD: Lobster 1000 Lbs; POWER REQUIRED: Refrigeration/Filtration: 15 Amps, 220V, 60Hz; Pump: 5 Amps, 115V, 60Hz

DIMENSIONS: UNIT: 48"L x 29"W x 53"H; Refrigeration Pack: 27"L x 19"W x 16"H; SYSTEM CAPACITY: 110 Gallons; RECOMMENDED LOAD: Lobster 75-100 Lbs.; Catfish 50-60 Lbs.; Trout 35 Lbs.; ELECTRICAL SUPPLY: 115 VAC / 60Hz, 15 AMPS
